RDL Active Two-Pair Receiver - Twisted Pair Format-A - stereo phono jack outputs

DS-TPR2A

$519.60

* Ex GST. Check with us for Discounts and the latest Trade pricing!

  • Two Unbalanced -10 dBV Phono Jack Audio Outputs
  • L (Left) Output From Pair B; R (Right) From Pair C
  • Signal and Power Pair Pass-Through on RJ45s
  • Remote Powering through Twisted Pair Cable
  • Fused Local Power Feeds all Connected Modules
  • Local Power Input on Terminal Block
  • Blue LED Indicates Module is Powered
  • Daisy-Chain with Additional Format-A Receivers
  • Studio-Quality Precision Active Balanced Circuitry

The TPR2A modules are two-pair audio receiving modules compatible with RDL Format-A twisted pair products. These modules are designed to be mounted in wall boxes, cabinets or other enclosures that allow users to connect external equipment. The D and DS models mount in RDL WB-1U and WB-2U wall boxes, or in standard US electrical boxes. The D-TPR2A features a white front-panel laminate with gray lettering that matches RDL Decora style remote controls. The DS-TPR2A is constructed of stainless steel to coordinate with RDL Decora style stainless steel remote controls in commercial/industrial installations.

The TPR2A modules feature two RCA phono jack outputs, one for the left channel output and one for the right channel. The audio signals received from pairs B and C of the twisted pair cable are buffered to drive the output jacks at the standard -10 dBV consumer level.
