AVMATRIX 1RU 8x8 3G-SDI Matrix Switcher

MSS0811

$1,688.00

* Ex GST. Check with us for Discounts and the latest Trade pricing!

AVMatrix MSS0811 8x8 3G-SDI Matrix Switcher

The compact SDI routing switcher MSS0811 has 8 inputs and 8 outputs, supports standard 3G/HD/SD SDI rates, automatic bypass of non-standard rates between 20 Mbit/s and 3 Gbit/s, and passes all SDI embedded audio/ancillary data. It’s conveniently control by front panel button, keyboard via USB and PC software via LAN/RS-232.

Features:
  • 8x3G-SDI inputs, 8x3G-SDI outputs
  • SDI input signal auto detection & equalization
  • Level A and level B singal supported
  • Pass all ancillary data and embedded audio
  • DVB-ASI interface compatible
  • Free PC software control: LAN, RS-232
  • Front panel buttons control & USB keyboard
  • Redundant power design

Powerful Signal Routing
This matrix includes multi format technology so it can auto detect multiple video format sources of SD/HD/3G-SDI (level A & B) and DVB-ASI signals at the same time and route the multiple video destination in NTSC and PAL SD, 720, 1080 at any frame rate.
